RoyalRay
Shenzhen RoyalRay Science and Technology Co., Ltd. specializes in the development, production, and sale of RFID reader products.
Partner Types
Products
About RoyalRay
Shenzhen RoyalRay Science and Technology Co., Ltd. is dedicated to providing RFID reader products and system solutions. All products are fully self-proprietary intellectual property and cover 125kHz, 134.2kHz, 13.56MHz, 860-940MHz, 2.45GHz multiple frequency bands and ISO14443A/B, ISO15693, HF EPC, UHF EPC Gen2(ISO18000-6C), ISO18000-6B international standards. Our products have acquired CE certification in the EU, FCC certification in the USA and NCC, KCC, EK and approval via Taiwan, Korea companies. RoyalRay RFID products have established an industrial standard with their stability, sensitivity, conformity and high performance to price ratio. RoyalRay focuses on delivering creative product concepts, delivering considerate service, and striving to realize value for our customers
Headquarters
Suite FC (West Wing), 4F, A1 Building/Bldg, Xiufeng Industrial Park, No.2 Xiufeng Road/Rd, Buji Town, Longgang District Shenzhen, Guangdong Sheng China 518112- Website
- https://www.rr-rfid.com/
Industry Focus:Manufacturing
Impinj Products: Impinj Reader Chips and Modules
Partner Operates In: APAC EMEA LATAM North America
Primary Impinj Partner Network Track: OEM
Authorized Reseller: No
Partner Products
Reader
7881ADV Ex10 Fixed Reader(4-Port)
The Impinj Connected RRU7881ADV is designed on an E710 chip. It maximizes anti-collision capability and embeds an Android 10 OS platform with abundant peripheral interfaces. It is the best choice for a high-end RFID system in fields such as warehousing, logistics, apparel, production and retail.
# of Antenna Ports4
ConnectivityBluetooth; GPIO; LAN; Serial; USB; Wi-Fi
EnvironmentNon-Rugged
Impinj Reader ChipImpinj E710
Max Output Power (dBm)33
Power SourcePoE+; Power Adapter
Reader Form FactorFixed
Learn More7189Lite Ex10 Fixed Reader(8-Port)
The Impinj Connected RRU7189LITE reader is designed on E710. It maximizes anti-collision capability and features high sensitivity and throughput. Ensuring consistently high performance over time, it is ideal for RFID systems in fields such as warehousing, logistics, apparel, and production lines.
# of Antenna Ports8
ConnectivityGPIO; LAN; Serial; USB
EnvironmentNon-Rugged
Impinj Reader ChipImpinj E710
Max Output Power (dBm)33
Power SourcePoE+; Power Adapter
Reader Form FactorFixed
Learn More7199Lite Ex10 Fixed Reader(16-Port)
The Impinj Connected RRU7199LITE is designed on E710. It maximizes anti-collision capability and features high sensitivity and throughput. Ensuring consistently high performance over time, it is ideal for RFID systems in fields such as warehousing, logistics, apparel, and production lines.
# of Antenna Ports16
ConnectivityGPIO; LAN; Serial; USB
EnvironmentNon-Rugged
Impinj Reader ChipImpinj E710
Max Output Power (dBm)33
Power SourcePoE+; Power Adapter
Reader Form FactorFixed
Learn More7182DL Ex10 Temp.Measuring Fixed Reader(4-Port)
RRU7182DL is a high-performance UHF RFID reader with fully independent intellectual property design. It incorporates a proprietary efficient signal processing algorithm that ensures high read rates while enabling fast tag reading, writing, and temperature measurement.
# of Antenna Ports4
ConnectivityGPIO
EnvironmentNon-Rugged
Impinj Reader ChipImpinj E710
Max Output Power (dBm)33
Power SourcePoE+; Power Adapter
Reader Form FactorFixed
Learn More6dBi Ex10 IOT Integrated RFID Reader
RRU7001-6dBi is a high-performance UHF RFID integrated Reader, designed with fully proprietary intellectual property rights. It combines a proprietary, efficient signal processing algorithm that maintains a high identification rate while achieving rapid readessin/write processing of RFID tags.
# of Antenna Ports0
ConnectivityGPIO; LAN; Wi-Fi
EnvironmentNon-Rugged
Impinj Reader ChipImpinj E710
Max Output Power (dBm)33
Power SourcePoE+; Power Adapter
Reader Form FactorIntegrated
Learn MoreModule
1515 Ex10 UHF RFID Module(1-Port)
Based on the E310 chip design and Impinj Connected. Featuring an ultra-small size, low power consumption, low cost, SMD form factor, maximum RF output of 27dBm, and real-time temperature monitoring, making it the best choice for various small desktop and mobile devices.
# of Antenna Ports1
Dimension Length (mm)15
Dimension Width (mm)15
Impinj Reader ChipImpinj E310
Max Output Power (dBm)27
Read Rate350
Learn More1717 Ex10 UHF RFID Module(1-Port)
Based on the E310 chip design and Impinj Connected. Featuring an ultra-small size, low power consumption, low cost, SMD form factor, maximum RF output of 27dBm, and real-time temperature monitoring, making it the best choice for various small desktop and mobile devices.
# of Antenna Ports1
Dimension Length (mm)17
Dimension Width (mm)17
Impinj Reader ChipImpinj E310
Max Output Power (dBm)27
Read Rate350
Learn More2121 Ex10 UHF RFID Module(1-Port)
Based on the E710 chip design, Impinj Connected small size, high performance, low cost, maximum RF output power of 27dBm and real-time temperature monitoring make it the best choice for integration in various mobile devices. Sub-versions based on the E510 and E310 are available.
# of Antenna Ports1
Dimension Length (mm)21
Dimension Width (mm)21
Impinj Reader ChipImpinj E710
Max Output Power (dBm)27
Read Rate1000
Learn More7180MG Ex10 UHF RFID Module(1-Port)
Based on the E710 chip design, the Impinj Connected product maximizes the chip potential with outstanding anti-collision capability. The advanced thermal balance design ensures consistently high performance over time, making it the best choice for handheld and other RFID devices.
# of Antenna Ports1
Dimension Length (mm)56
Dimension Width (mm)36
Impinj Reader ChipImpinj E710
Max Output Power (dBm)33
Read Rate1000
Learn More7182M Ex10 UHF RFID Module(4-Port)
Based on the E710 chip design, this Impinj Connected product maximizes chip potential with outstanding anti-collision capability. It is ideal for high-performance RFID system in fields such as warehousing, logistics, apparel, production lines and retail.
# of Antenna Ports4
Dimension Length (mm)67
Dimension Width (mm)51
Impinj Reader ChipImpinj E710
Max Output Power (dBm)33
Read Rate1000
Learn More
