CAEN RFID
CAEN RFID designs and manufactures RAIN RFID readers, from module to fixed and mobile. The offering is completed by dual frequency RAIN/NFC loggers.
Partner Types
Products
About CAEN RFID
CAEN RFID was founded in 2006 as a private-owned Italian company, but its activities started in 2003 as the RFID division of CAEN SpA. It has been the first European company to design, produce, and market a UHF RFID reader. It is a partner of the most important associations, including EPCglobal and ETSI, participating in the definition of the standards. The Management, Technical and Commercial teams are young, dynamic, and greatly experienced with everyday RFID applications. All our staff has been previously involved in the experience within CAEN SpA, a world leader in electronic instrumentation for Nuclear and Particle Physics. CAEN electronics is always at the forefront of technology and has become a “de facto” standard in the most important Physics labs around the world
Headquarters
VIA VETRAIA 11 VIAREGGIO, Lucca Italy 55049- Website
- www.caenrfid.com
Industry Focus:High-Tech
Impinj Products: Reader Chips
Partner Operates In: APAC EMEA LATAM North America
Primary Impinj Partner Network Track: OEM
Authorized Reseller: No
Partner Products
Module
Lepton7 (R7100C)
The Lepton7 (Model R7100C), an embedded reader of the easy2read© product line, is an ultra-compact reader for low-power, high-performance RAIN RFID applications. With programmable output power from 10dBm to 30dBm, the reader can detect tags at more than 5 mt of distance (depending on antenna and tag dimensions). Due to its low power consumption, the module is specifically designed to be easily integrated in battery-powered devices.
# of Antenna Ports1
Dimension Length (mm)29
Dimension Width (mm)32
Impinj Reader ChipImpinj E710
Max Output Power (dBm)30
Read Rate700
Learn MoreLepton9 (R9100C)
The Lepton9 (Model R9100C), an embedded reader of the easy2read© product line, is an ultra-compact reader for low-power, high-performance RAIN RFID applications. With programmable output power from 10dBm to 30dBm, the reader can detect tags at more than 5 mt of distance (depending on antenna and tag dimensions). Due to its low power consumption, the module is specifically designed to be easily integrated into battery-powered devices. The radio frequency core of the module is based on the Impinj E910 chipset that permits to achieve fast reading speed and to be used in dense reader and dense tag environments for top-class rated performances. The compactness of the device and the surface mount technology allow the Lepton9 to be embedded inside the new small form factor industrial handhelds, smartphone accessories, and other compact form factor devices. The Lepton9 complies with and can operate in European and US regulatory environments. Thanks to its multiregional capability, it’s ideal for integration in devices requiring compliance to different geographical regions. The Lepton9 is pin-to-pin compatible with the Impinj RS1000 and RS500 and with the CAEN RFID Hadronmini module, making it a perfect replacement for these devices.
# of Antenna Ports1
Dimension Length (mm)29
Dimension Width (mm)32
Impinj Reader ChipImpinj E910
Max Output Power (dBm)30
Read Rate1000
Learn MoreLepton3 (R3100C)
The Lepton3 (Model R3100C), an embedded reader of the easy2read© product line, is an ultra compact reader for low power, medium performance RAIN RFID applications. With programmable output power from 10dBm to 25dBm, the reader can detect tags at more than 3 mt of distance (depending on antenna and tag dimensions). Due to its low power consumption, the module is specifically designed to be easily integrated in battery powered devices.
# of Antenna Ports1
Dimension Length (mm)29
Dimension Width (mm)32
Impinj Reader ChipImpinj E310
Max Output Power (dBm)25
Read Rate400
Learn MoreHadron (R4320C)
The Hadron (Model R4320C) is a RAIN RFID multiregional module for high-performance applications. With programmable output power from 10dBm to 31.5dBm, the reader reaches top reading performances being able to detect RAIN tags from a distance of 9m.
# of Antenna Ports4
Dimension Length (mm)60
Dimension Width (mm)42
Impinj Reader ChipImpinj R2000
Max Output Power (dBm)32
Read Rate200
Learn MoreHadron Mini (R1271C)
High-performance 1-port module with programmable output power from 10 to 27dBm, the reader can detect tags at more than 3 mt of distance. Due to its low power consumption, the module is specifically designed to be easily integrated in battery-powered devices.
# of Antenna Ports1
Dimension Length (mm)32
Dimension Width (mm)29
Impinj Reader ChipImpinj R2000
Max Output Power (dBm)27
Read Rate140
Learn MoreHandheld Reader
Reader
trID - R1210I
The trID (Model R1210I) is a slim RAIN RFID reader of the easy2read© product line with an integrated antenna for short-range applications. The reader hosts an internal rechargeable battery and can operate both in wired mode, using a USB cable, or in wireless mode through the Bluetooth® interface. Thanks to the Bluetooth® communication interface, the trID can be connected to any Bluetooth® enabled host such as a PC, a smartphone, a PDA, or a tablet for RAIN RFID readings. The reader is compatible with Windows 8/10, Windows CE/Mobile, Android, and iOS operating systems. The device supports Bluetooth Low Energy (BLE) and Bluetooth classic communication to provide maximum usage flexibility, including the HID profile for keyboard emulation. The trIDs slim form factor permits the reader to be embedded in jewelry trays or to use it on a desk for document tracking or in healthcare environment to track surgery or dental tools.
# of Antenna Ports4
ConnectivityBluetooth; USB
EnvironmentNon-Rugged
Impinj Reader ChipImpinj R2000
Max Output Power (dBm)27
Power SourceBattery; Power Adapter
Reader Form FactorDesktop
Learn MoreQuattro - R4321P
Smart 4-port RAIN RFID Long Range Reader
# of Antenna Ports4
ConnectivityGPIO; LAN; USB
EnvironmentNon-Rugged
Impinj Reader ChipImpinj R2000
Max Output Power (dBm)31.5
Power SourcePoE; Power Adapter
Reader Form FactorFixed
Learn MoreProton - R4320P
Industrial 4-port RAIN RFID Long Range Reader
# of Antenna Ports4
ConnectivityGPIO; LAN; Serial
EnvironmentRugged
Impinj Reader ChipImpinj R2000
Max Output Power (dBm)31.5
Power SourceIn-Vehicle; PoE; Power Adapter
Reader Form FactorFixed
Learn More
