NFC vs. RFID (and RAIN RFID): What's the Difference?
NFC and RFID are both similar technologies that communicate data at a distance. We explain what sets them apart.
NFC and RFID are both enjoying enormous growth at the moment, and they’re often mentioned in the same breath. But what is the relationship between the two?
Here’s a brief rundown of what NFC and RAIN RFID have in common, and some of the things that make each of them unique.
What's the difference between NFC and RFID?
NFC and RFID (and RAIN RFID) are closely related. In fact, they're family. While both are used to communicate at a distance, the range at which they communicate is what sets them apart. RFID is a form of wireless communication that uses radio waves to identify and find objects at a distance of up to several meters, without direct line of sight. RFID systems that operate in the frequency band that covers the range from 300 MHz to 3 GHz are called UHF, or "ultra-high frequency" RFID. UHF RFID is often called RAIN RFID, a name that brands passive UHF RFID products and technologies that adhere to certain industry standards and protocols.
NFC, on the other hand, operates at close range, typically around 5 cm and is used for secure consumer transactions.
What is RFID?
RFID, or radio frequency identification, is a broad category of wireless communication using radio waves to locate and identify objects. RFID chips are often embedded in special tags or labels, each with its own antenna, and these tags can be read by RFID readers.
RAIN RFID chips need no dedicated power source to operate; they are powered by the radio waves sent by the RAIN RFID reader. These are referred to as “passive” chips, and the highest-performing — such as Impinj RAIN RFID tag chips — can be detected at distances of up to 10 meters (30 feet).
Some RFID chips make use of a battery to extend their range and capability. These are called “active” or “battery-assisted passive” chips, and readers can detect these tags from farther away, in some cases as far as 100 meters (330 feet).
To uniquely identify a tagged item, each RAIN RFID tag contains a number that corresponds to that item in a database. RAIN RFID readers, which operate at ultra-high radio frequencies (UHF), can read up to 1,000 individually tagged objects in one second.
These capabilities make RAIN RFID solutions ideal for tracking and counting inventory and workplace assets in retail and industrial environments. The technology plays a big role in getting goods and services to the public.
A typical use of RAIN RFID tracking might find a worker in a warehouse scanning a shipment of products and accessing information regarding the size, variety, origin, destination, shipping schedule, and number of items in a collection of shipping crates. This happens in seconds and with 99% accuracy or better.
As products are shipped, a RAIN RFID system can track items leaving a warehouse, arriving to a store backroom, and transitioning to the sales floor. Because of these benefits, RAIN RFID has become a valuable technology for the handling and shipping of goods.
RAIN RFID systems:
- Enable tracking items, including assets and inventory, with near-100% accuracy
- Can count up to 1,000 items per second
- Do not require line-of-sight to read tagged objects
- Can read tags at close range or from a distance
- Can link customers to supplemental information about goods and services
- Can feed information to relevant databases in real-time
What is NFC?
Devices featuring NFC, or near-field communication, also use radio signals to function, but only at a very close range. NFC RFID is often used by consumers, allowing them to make secure purchases and learn more about their selections. The technology works well for contactless transactions such as ticket confirmations, sales transactions, and the like — for instance, when someone pays by bringing an NFC-enabled card or smartphone within a few centimeters of a reader.
NFC was designed to be a secure form of data exchange, leading to the credit card industry being one of the earliest to embrace the technology. This security comes from the ability of an NFC device to assign a unique code to every transaction, preventing unauthorized attempts to access a cardholder’s account.
NFC is used to read one tag or item at a time, compared to RAIN RFID where up to 1,000 items can be read simultaneously. Data transmission rates also are slower with NFC compared to RAIN RFID.
Another attribute of NFC is its ability to direct people to information via their smartphones. If a product has an NFC tag, consumers interested in learning more about it can scan the tag and receive a link to sales information, manufacturer details, and more.
NFC systems:
- Are used to read one tag or item at a time
- Feature high security for consumer payment and financial transactions
- Offer instant reading of NFC-equipped bank cards and smartphones
- Can link customers to supplemental information about goods and services
NFC vs. RFID: Short and sweet
RFID is an overarching term for technology that includes RAIN and NFC.
NFC operates at very close ranges and is most commonly used for secure consumer transactions.
Today, RAIN RFID largely tracks things before they get to consumers. However, everyday consumers are experiencing RAIN systems more and more often.
For instance, Delta Airlines uses RAIN RFID to track baggage and provide live location information to travelers. Self-checkout kiosks powered by RAIN RFID eliminate the need for individually scanning barcodes. And new Impinj reader chips are unlocking new capabilities for consumer devices.
Learn more about RAIN RFID and the Impinj platform, which have uses far beyond what is outlined here. Millions of products and assets are tracked each day in a variety of industries and through many other applications worldwide — industries like agribusiness, healthcare, manufacturing, retail, travel, and logistics, to name only a few.
