Beijing Silion Technology Corporation
Provides leading RAIN RFID module products for RFID applications.
Partner Types
Products
Services
About Beijing Silion Technology Corporation
Beijing Silion Technology Corp., Ltd. is a pioneering and cutting-edge RFID hardware solutions provider for 16 years, since 2005. We design and manufacture a full series of RFID hardware products including a UHF RFID reader, integrated reader, UHF RFID module, and related UHF RFID products. Silion acquired ISO9001:2015 quality system certification and more than 40 RFID independent intellectual property rights. We stand for superior quality and creativity and have been approved as a Gold Partner by RFID global brand Impinj Inc. With a senior and experienced RFID technical team, we are devoted to offering customers optimal solutions and outstanding services. With Silion product usage, enterprises reduce operational expenses and improve work efficiency
Headquarters
5/F, Block A, Jinyu International Center, No.3, Longyu North St., Changping Dist. Beijing, Beijing Shi China 102200- Website
- en.silion.com.cn
Industry Focus:Manufacturing
Impinj Products: Impinj Reader Chips and Modules
Partner Operates In: APAC EMEA LATAM North America
Primary Impinj Partner Network Track: OEM
Authorized Reseller: No
Partner Products
Reader
4 Ports RFID Reader SLR5623
4 reverse TNC connectors supporting 4 antennas. Includes PoE power supply, all-aluminum alloy housing, which is helpful in heat dissipation
# of Antenna Ports4
ConnectivityGPIO; LAN; Serial
EnvironmentRugged
Impinj Reader ChipImpinj R2000
Max Output Power (dBm)33
Power SourcePoE; Power Adapter
Reader Form FactorFixed
Learn More6dbi Built-in Antenna Integrated UHF RFID Reader SLR1215
Integrated 6dbi antenna UHF RFID reader. 5-30dbm adjustable, smart size, and RJ45 options.
# of Antenna Ports1
ConnectivityGPIO; LAN; Serial
EnvironmentRugged
Impinj Reader ChipImpinj R2000
Max Output Power (dBm)30
Power SourcePower Adapter
Reader Form FactorIntegrated
Learn MoreModule
UHF RFID Module SLR1200
The SLR1200 module has a single MMCX connector supporting one antenna, 5-30dBm adjustable RF power, and an open frequency 860-960MHz. High-performance anti-collision recognition algorithm, real-time monitoring of onboard temperature. Good for handheld and PDA.
# of Antenna Ports1
Dimension Length (mm)56
Dimension Width (mm)36
Impinj Reader ChipImpinj R2000
Max Output Power (dBm)30
Read Rate700
Learn MoreUHF RFID Module SLR1100
The SLR1100 module has 4 MMCX connectors supporting 4 antennas, 5-30dBm adjustable RF power, open frequency 860-960MHz, and metal housing that is helpful in heat dissipation.
# of Antenna Ports4
Dimension Length (mm)69
Dimension Width (mm)43
Impinj Reader ChipImpinj R2000
Max Output Power (dBm)30
Read Rate700
Learn MoreUHF RFID Module SLR6100
The SLR6100 UHF RFID module reader has 16 ports - widely used in vending machines and multiple antenna connecting applications.
# of Antenna Ports16
Dimension Length (mm)130
Dimension Width (mm)112
Impinj Reader ChipImpinj R2000
Max Output Power (dBm)30
Read Rate700
Learn MoreSilion SIM7100 Module
Silion SIM7100 Module is a new RFID module is based on the next-generation Impinj RAIN RFID E710 reader chip. Enables better performance using a single port.
# of Antenna Ports1
Dimension Length (mm)56
Dimension Width (mm)36
Impinj Reader ChipImpinj E710
Max Output Power (dBm)33
Read Rate900
Learn MoreSilion SIM7200 Module
The UHF high-performance module Silion SIM7200 Module is based on the next-generation Impinj E710 RAIN RFID reader chip, designed for high-performance RFID devices and fixed readers. The SLR7200 module provides four SMA antenna ports that support RF outputs up to 33 dBm. The module's high sensitivity, good RF performance, and advanced anti-jamming design make it a preferred choice for fixed RFID devices.
# of Antenna Ports4
Dimension Length (mm)73
Dimension Width (mm)46
Impinj Reader ChipImpinj E710
Max Output Power (dBm)33
Read Rate900
Learn MoreSilion SIM7300 Module
The 8-port RFID SIM7300 Module is based on the next-generation Impinj E710 RAIN RFID reader chip. The SLR7300 module can be used for multiple antenna time-sharing applications; when the 8dBi antenna is used, the reading distance is more than 12 meters; the excellent multi-label anti-collision algorithm, the inventory is more than 900tags/s; the large-area aluminum alloy thermal conductive panel is used. Excellent heat dissipation.
# of Antenna Ports8
Dimension Length (mm)79
Dimension Width (mm)91
Impinj Reader ChipImpinj E710
Max Output Power (dBm)33
Read Rate900
Learn MoreSilion SIM7400 Module
The 16-port RFID Silion SIM7400 Module is based on the next-generation Impinj E710 RAIN RFID reader chip. The SLR7400 module can be used for multiple antenna time-sharing applications; when the 8dBi antenna is used, the reading distance is more than 12 meters; the excellent multi-label anti-collision algorithm, the inventory is more than 900tags/s; the large-area aluminum alloy thermal conductive panel is used. Excellent heat dissipation.
# of Antenna Ports16
Dimension Length (mm)79
Dimension Width (mm)179
Impinj Reader ChipImpinj E710
Max Output Power (dBm)33
Read Rate900
Learn MoreSilion SIM7500 Module
The coin size UHF RFID Silion SIM7500 Module is based on a next-generation Impinj E710 RAIN RFID reader chip, designed for low-cost RFID handheld devices and mobile readers. The SLR7500 module's low power consumption is only coin size and is good for mobile devices. Compatible with Impinj E510 and E310 chipset.
# of Antenna Ports1
Dimension Length (mm)28
Dimension Width (mm)28
Impinj Reader ChipImpinj E710
Max Output Power (dBm)23
Read Rate100
Learn MoreHandheld Reader
Wearable Handheld UHF RFID Reader
Wear gloves to read RFID tags automatically, help workers realize hands-free, it can be widely used in logistics and asset management applications.
Learn More
