Shenzhen Hopeland
Hopeland Technologies Co, Ltd. located in Shenzhen, China, is a national-level high-tech enterprise that passed ISO9001, ISO14001, OHSAS18001 system certifications, began RFID-based R&D in 2009.
Partner Types
Products
About Shenzhen Hopeland
To achieve the era of big data for customers, our vision is: Commit to providing more accurate, effective, and real-time data collection, turn on the real value of data. Since 2009, we are specialized in researching, developing, and manufacturing a series of high-performance UHF RFID readers, handheld terminals, Antennas, RFID Tags, Middleware, System software, etc. To support the success of partners, under the guidance of core values: Customer-centric, long-term, to be excellent and achieve employees, we sell products into more than 80 countries & regions worldwide with multiple certifications such as CE, FCC, SRRC, NBIT, etc. Our solutions are also widely used in ETC solutions, Intelligent Parking, Aviation, Smart Retail, Medical, Smart Grid, Assets Management, Warehousing & Logistic, Supply Chain, Industry 4.0, and so on. Keeping innovation is the only way to develop, and we are always striving for a better future with long-term partners together
Headquarters
3F, F5# Bldg., TCL International E-city, Zhongshan Park Road, Xili Street, Nanshan District Shenzhen, Guangdong China 518052- Website
- www.hopelandrfid.com
Industry Focus:Other
Impinj Products: Impinj Reader Chips and Modules
Partner Operates In: APAC EMEA LATAM North America
Primary Impinj Partner Network Track: OEM
Authorized Reseller: No
Partner Products
Handheld Reader
Hopeland Wing series HY820 long reading Android Handheld
The Hopeland Wing series HY820 is a highly integrated Android RFID handheld reader based on Octa-core /2.3GHz CPU, including camera, GPS, 1D&2D Barcode, Wi-Fi, Bluetooth, 4G. 15m reading and excellent multi-tag reading support wide applications.
Learn MoreModule
Hopeland Smart series HZ510/511 series UHF Module
The Hopeland Smart series HZ510/HZ511 is a miniaturized UHF RFID reading and writing module, which supporting up to 33dbm RF power output - good choice for integrated into handheld or reader writer.
# of Antenna Ports1
Dimension Length (mm)56
Dimension Width (mm)36
Impinj Reader ChipImpinj E710
Max Output Power (dBm)33
Read Rate600
Learn MoreHopeland Smart series HZ580 8 port UHF Module
UHF RFID 8-Port Module HZ580 HZ580 is UHF RFID reader module board for developing 8-port fixed RFID reader. Based on Impinj R2000 chip platform, with 8 channels of SMA interfaces for RFID antennas, it support multiple-tag and long range reading. Frequency: FCC, ETSI, CN, RU, KC Optional Air Protocols: ISO 18000-6C/C1G2,ISO 18000-6B
# of Antenna Ports8
Dimension Length (mm)78
Dimension Width (mm)88
Impinj Reader ChipImpinj R2000
Max Output Power (dBm)33
Read Rate600
Learn MoreHopeland HZ530 16 Port UHF reader Module
Smart series HZ530 16-Port UHF RFID Module is specialized module for developing 16-port fixed RFID reader and Smart RFID cabinet system. Based on Impinj R2000 chip platform, with 16 channels of SMA interfaces for RFID antennas, it support multiple-tag and long range reading. HZ540 module supports ISO 18000-6C/6B, EPC C1G2, GBT 29768-2013, GJB 7377.1 protocol, users can communicate with their own equipment through the UART-TTL pin on the interface, and its wide power supply range (DC4. 5V~6V) and the configured GPIO interface (IO1-IO4, IO1/IO2 as input, IO3/IO4 as output) can provide users with more choices. Due to the good card reading distance and multi-antenna design of the module, it can be used as a design solution for small readers.
# of Antenna Ports16
Dimension Length (mm)98
Dimension Width (mm)140
Impinj Reader ChipImpinj E710
Max Output Power (dBm)33
Read Rate800
Learn MoreHopeland HZ540 series 4 port UHF reader Module
HZ540 module is a miniaturized UHF RFID reader. The core components of the core platform adopts R2000 or E710 which is a high-performance highly integrated reader IC and integrated with analog RF front-end and baseband digital signal processing modules etc. 4 port version78.55mmx53.5mmx7.95mm
# of Antenna Ports4
Dimension Length (mm)78
Dimension Width (mm)54
Impinj Reader ChipImpinj E710
Max Output Power (dBm)33
Read Rate600
Learn MoreReader
Hopeland Shine series HH100 Android IoT-level integrated reader
The Hopeland Shine series HH100 RFID reader is an Integrated Smart IoT device designed based on Octa-core CPU, Android 9.0 OS, which is built with 9dbi antenna, extendable RF port, Wi-Fi, Bluetooth, 4G. Its IP67 industrial level support for all weather rugged environment.
# of Antenna Ports2
ConnectivityBluetooth; GPIO; LAN; Serial; Wi-Fi
EnvironmentRugged
Impinj Reader ChipImpinj E710
Max Output Power (dBm)33
Power SourcePoE; PoE+; Power Adapter
Reader Form FactorIntegrated
Learn MoreHopeland Smart series HZ340 4 port UHF reader
Powered by Impinj R2000 chipset, 4 or 8 SMA RF port optional, Simplified interface, lightweight version. Support RSSI, antenna detection, online update.
# of Antenna Ports4
ConnectivityGPIO; LAN; Serial
EnvironmentNon-Rugged
Impinj Reader ChipImpinj R2000
Max Output Power (dBm)33
Power SourcePower Adapter
Reader Form FactorFixed
Learn MoreHopeland Smart series HZ100 Integrated RFID Reader
Impinj Indy R2000 or E710 RAIN RFID chipset offer high performance Aluminum casting / waterproof housing apply to all weather industrial scenarios Various communication / software Interfaces helps faster application system Different developing languages SDK meet different developer needs Excellent communication protocol architecture support faster data processing algorithm Integrated design supports better deploy /installation / engineering / wiring Special application projects customized interfaces / data transferring prolongable Seamlessly compatible with RFID middleware for rapid implementation of large projects Widely used in E-parking, garbage truck, feeding vehicle, access control and so on
# of Antenna Ports1
ConnectivityGPIO; LAN; Serial
EnvironmentRugged
Impinj Reader ChipImpinj E710
Max Output Power (dBm)33
Power SourceBattery; Power Adapter
Reader Form FactorIntegrated
Learn MoreHopeland Sharp series HF380 UHF RFID reader
Powered by Impinj R2000 chipset for maximum tag detection performance. 0-30m reading range, ≥600 tags/sec Kinds of communication interfaces: RJ45, RS485, Wiegand, USB, Industrial, installation-friendly I/O connector. Support RSSI, antenna detection, online update RSSI & speed filters. Support Hopeland Web management platform and RFID middleware V2.O.
# of Antenna Ports8
ConnectivityGPIO; LAN; Serial; USB
EnvironmentNon-Rugged
Impinj Reader ChipImpinj R2000
Max Output Power (dBm)33
Power SourceBattery; In-Vehicle; PoE; Power Adapter
Reader Form FactorFixed
Learn MoreHopeland Shine series HH340 Android 4-Port RFID reader
The Hopeland Shine series HH340 RFID reader is a Split-type Smart IoT device designed based on an Octa-core CPU, Android 9.0 OS. with 4*TNC RF port, Powered by Impinj R2000 chipset / E710 RAIN RFID reader chip upgradeable Android OS-based open development environment Support MQTT provides real-time, reliable messaging services for connecting cloud servers. Support HTTP POST communication to send the tag data to the web URL directly Support to send the tag data to the specified database directly. Kinds of communication interfaces: RJ45, RS485, Wiegand, USB，Bluetooth，4G Industrial, installation-friendly I/O connector Support RSSI, antenna detection, online update RSSI & speed filters.
# of Antenna Ports4
ConnectivityBluetooth; GPIO; LAN; Serial; USB; Wi-Fi
EnvironmentNon-Rugged
Impinj Reader ChipImpinj E710
Max Output Power (dBm)33
Power SourceBattery; In-Vehicle; PoE; PoE+; Power Adapter
Reader Form FactorFixed
Learn More
